Check and report all the connecting objects (including Pin, Via, Cline and Shape) on each selected net and the minimum spacing with other nearby net objects.
The GraserWARE Minimum Spacing Report app app allows OrCAD® PCB Editor users to check all connecting objects (including Pin, Via, Cline and Shape) of the net selected by the user and the minimum spacing with other nearby net objects. The minimum spacing, coordinate location, subclass, nearby net name and both object types closest to the location between the specified net and the other nearby net will be reported. All etch subclasses can be measured together or individually. The spacing report is generated in Excel format.
