The CIS Row Color app allows designers to easily set the color of rows and text in the CIS explorer interface based on defined conditions.
Th CIS Row Color app allows users to highlight rows in OrCAD® Capture CIS explorer based on user defined conditions. With the app you can define a row color and/or a row text color. An example use model would be to set up rules to highlight rows based on part status. Red for obsolete. Yellow for unapproved. Green for approved.
This app provides extensive logic support so users can key off any CIS field and even develop rules based on a combination of fields using and/or logic.
